Description
- Power Handling:3250 Watts RMS / 6500 Watts Peak
- Xmax = 35mm one-way by 70% BL
- Heavily vented magnetic gap
- Spring Loaded Terminals
- Optimized high-velocity pole vent
- Innovative high-velocity cast-aluminum vented frame spacer ring
- Black aluminum 3 inch 8-layer voice coil
- Mega-Roll v.2 surround
- Custom tooled basket
- Large aluminum Faraday (shorting) Ring
- Stitched-On XL Tinsel Leads to prevent fatigue and failure
- Custom-tooled ultra-linear spider packs
| Sealed Enclosure | Not Recommended |
| Ported Enclosure | 7 cu.ft. net |
| Recommended Tuning | 32Hz |
| Recommended Port Area | 100 sq.in. |
| Displacement | .27 cu. ft. |
| Depth | 14.92" |
| Outside Diameter | 18.46" |
| Cut-Out | 16.68" |
| Physical Dimensions | Download |
