SUPERIOR PERFORMANCE: Our Quad Stack Power Subwoofer is engineered to include 4 magnets (220 Oz) for strong power handling and superior performance
-
PEAK POWER: 2400 WATTS
-
RMS POWER: 1200 WATTS
-
FREQUENCY RESPONSE: 28- 1,200Hz
-
SENSITIVITY: 86dB
-
PAPER + FIBERGLASS COMPOSITE CONE: The composite cone is made from a combination of paper and fiberglass, providing optimal sound quality and durability. Designed for high-powered performance, this cone ensures a stable and accurate bass response.
-
AIR CUSHION FOAM SURROUND: The air cushion foam surround enhances sound quality while the high excursion allows for maximum bass output.
-
VOICE COIL: This subwoofer boasts 3" 4-layer black aluminum (BASV) dual voice coil for high power output.
-
DIE CAST ALUMINUM BASKET: This subwoofer features a powdered black paint die cast aluminum basket which provides excellent overheat protection, reduces excess unwanted resonance, and maximizes durability with optimal sound quality.
-
QUAD-STITCHED SURROUND: The blue stitching of the subwoofer greatly reinforces the cone and surrounds, ensuring a longer lifespan.
-
MULTI-CONNECT TERMINALS: This subwoofer is designed with multi-connect terminals, which allow for easy wiring of your subwoofer in either parallel or series configurations.
-
MOUNTING DEPTH: 7-7/8” (200mm)
-
IMPEDANCE: 2×4 Ohms
Description:
Experience powerful, high-quality bass with our 12” Quad Stack High Power Subwoofer. With 2400 watts of P.M.P.O. power and a 3" 4-layer dual voice coil, this subwoofer delivers crisp, clear sound at a frequency response of 28- 1,200Hz. Its Large Inverted Composite Fiberglass Cone provide superior performance, while the easy connect terminals allow for convenient wiring. Upgrade your car audio system today with our subwoofer!
TXX-BDD4-12-English/Spanish Product Manual
