Description
| Model | AAB-1000.2D |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 15 - 20000 Hz |
| 1 Ohm RMS Power (14.4 V) | 1000 W x 2 |
| 1 Ohm RMS Power (12 V) | 850 W x 2 |
| 2 Ohm RMS Power (14.4 V) | 525 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 300 W x 2 |
| Minimum permissible load on the channel | 1 Ohm |
| Input SPL | 0.5 - 8 V |
| Low pass filter | 50 - 10000 Hz |
| High pass filter | 15 - 1000 Hz |
| Crossover | 12 dB/Oct |
| Input terminal | 4 Ga |
| Output terminal | 8 Ga |
| Damping factor | ≥ 600 |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ≥ 105 dB |
| Size (W×L×H) | 8.46 × 9.72 × 2.89 inch |
| Gross weight | 8.60 lb (3.90 kg) |
