Description
-
Type: Midrange
-
Size: 8"
-
Frequency Response: 150 – 10,000 Hz
-
Package Quantity: Pair
Power Handling:
-
RMS Power: 300 W
-
Max Power: 600 W
Build & Materials:
-
Voice Coil Size: 1.75"
-
Voice Coil Wire: Copper-Clad Aluminum (CCAW)
-
Cone Material: Pressed Paper
-
Magnet Type: Ferrite
-
Frame: Aluminum
Performance Characteristics:
-
Impedance: 4 Ohm
-
Sensitivity (SPL): 98.1 dB
-
Resonance Frequency (Fs): 155 Hz
-
Total Q Factor (Qts): 0.41
-
BL (Magnetic Force): 9.70
-
Vas (Equivalent Air Volume): 5.30 L
Mounting Dimensions:
-
Mounting Depth: 89.0 mm
-
Cut-Out Diameter: 193.0 mm
Shipping Weight:
-
Gross Weight: 7.80 kg
