Description
Specifications
| Model | ASA-550.4 |
| Class | D |
| Number of the channels | 4 |
| Frequency response | 10-20000 Hz |
| 1 Ohm RMS Power (14.4 V) | 550W x 4 |
| 2 Ohm RMS Power (14.4 V) | 350 W x 4 |
| 4 Ohm RMS Power (14.4 V) | 225 W x 4 |
| 2 Ohm RMS Power (Bridge) | 1100W x 2 |
| 4 Ohm RMS Power (Bridge) | 700 W x 2 |
| Minimum permissible load on the channel | 1 Ohm |
| Minimum permissible load in a bridge connection | 2 Ohm |
| Low pass filter | 50-1200 / 500-12000 Hz |
| High pass filter | 10-1200 / 100-12000 Hz |
| Crossover | 12 dB/Oct |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 16V |
| Signal-to-noise ratio | ≥ 90 dB |
| Size (LxWxH) | 16.93 x 9.45 x 2.5 inch |
