Specifications
| Model | ASA-10000.1 |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 10 - 250 Hz |
| 1 Ohm RMS Power (14.4 V) | 10000 W |
| 1 Ohm RMS Power (12 V) | 7120 W |
| 2 Ohm RMS Power (14.4 V) | 6130 W |
| 4 Ohm RMS Power (14.4 V) | 3550 W |
| Minimum permissible load on the channel | 1 Ohm |
| Low pass filter | 35 - 250 Hz |
| Crossover | 24 dB/Oct |
| Subsonic filter | 10 - 50 Hz |
| Bass frequency adjustment | 35 - 250 Hz |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 16 V |
| Signal-to-noise ratio | ≥ 85 dB |
| Size (WxLxH) | 9.4 x 38.3 x 2.5 inch |
