Diablo DB-15XL 15" 3000W RMS Subwoofer DVC
Diablo DB-15XL 15" 3000W RMS Subwoofer DVC
Diablo DB-15XL 15" 3000W RMS Subwoofer DVC
Diablo DB-15XL 15" 3000W RMS Subwoofer DVCDiablo DB-15XL 15" 3000W RMS Subwoofer DVCDiablo DB-15XL 15" 3000W RMS Subwoofer DVC

Diablo DB-15XL 15" 3000W RMS Subwoofer DVC

Coil Configuration: Dual 1 Ohm
Price:
$479.99
Stock:
In stock

Moon Points Earn 479 Moon Points when you buy this item.

Description

DIABLO AUDIO DB-15XL

15" 7000W Peak Dual 2-Ohm/1-Ohm DVC Car Subwoofer

Key Features:

  • 15-inch high-performance car subwoofer
  • Die-cast aluminum basket
  • Non-pressed paper cone
  • Foam surround with rubber gasket
  • Tinsel woven leads on Nomex spider
  • High-efficiency FEA-optimized motor design
  • Dual high-temperature long copper voice coils
  • Built for high-power bass applications
Specifications:

  • Impedance: 1 Ohm/2 Ohm
  • RMS Power: 3000 W
  • Peak Power: 7000 W
  • Voice Coil: 3.3-inch, 4-layer copper voice coil
  • Magnet Structure: 3 pcs Y35 magnets (Total 313 oz)
  • Sensitivity (SPL): 85.5 dB
  • Resonant Frequency (Fs): 29.4 Hz
  • Qes: 0.55
  • Qms: 6.15
  • Qts: 0.5
  • Vas: 49.33 liters
  • BL: 25 T·L
  • Xmax: 21 mm
  • DC Resistance (Re): 4 Ω
  • Recommended Ported Box Volume: 3.0 – 3.5 ft³
  • Mounting Depth: 260 mm
  • Cutout Diameter: 356 mm
  • Overall Diameter: 395 mm
  • Net Weight: 21.6 kg (47.6 lbs)
