DS18 CANDY-XXL4B Compact Full-Range Class D 4-Channel Amplifier 880W


Price:
Sale price$299.95
Stock:
In stock

Payment & Security

American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

Digital 4-Channel Amplifier

DS18’s CANDY-XXL4B is a 4-channel digital amplifier engineered for massive volume, clean signal, and pro-level tuning — all in a compact 13” footprint that hits hard and runs cool.

Extreme Output Without the Bulk
The CANDY-XXL4B delivers 3200W peak resulting in clean RMS output across all channels at: 4 x 220W @ 4Ω, 4 x 400W RMS @ 2Ω, and 2 x 750W @ 4Ω Bridged!

Bridge It. Boost It. Tune It.
Fine-tune your system with adjustable crossovers (40Hz–2kHz) and selectable bass boost (0/6/12dB).

OEM-Ready with Pro Installer Features
Drop it in fast with Hi-Level Inputs and Auto Turn-On — perfect for factory system upgrades. This means easy installs in tight spaces, stealth builds, or even powersports applications.

Built to Last.
A high-efficiency Class D design, dual 50A fuses, and full thermal, overload, and short protection make the CANDY-XXL4B ready for anything your system throws at it.

Choose the CANDY-XXL4B when you're ready for harder, cleaner, and LOUDER sound!



SPECS

SKU
CANDY-XXL4B
Total Watts (Peak)
3200W
RMS Power @ 4 Ohm
220W x 4
RMS Power @ 2 Ohm
400W x 4
RMS Power @ 4 Ohm Bridge
750W x 2


Audio

Frequency Response
20Hz~20KHz
Signal to Noise Ratio
70dB
Efficiency @ 4ohm
>75%
Damping Factor
26
Input Impedance
10K ohm
Channel Separation
50dB
Total Harmonic Distortion (THD)
0.50%
Low Level Input Range
0.2~6V
High Level Input
Yes, 2~10V
Selectable X-Over
LPF/FULL/HPF
X-Over Filter Range
40Hz~2kHz
Bass Boost Range
0/6/12dB
Bass Boost Frequency
50Hz
Infrasonic Filter
No
Phase Selector
No


Features

Amplifier Class
Digital
Amplifier Type
Stereo Full Range
Number of Channels
4
Minimum Impedance
2 ohm St / 4 ohm Bridge
Led Indicator
Power / Protection
Power Input Terminal Size
4Ga
Fuse Size
50A x 2
Remote Level Control
No
Cooling Fan
No
Voltmeter
No
Thermal Protection
Yes (>158F)
Over-Load Protection
Yes
DC Output Protection
No
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes (9-16v)
Clipping Protection
No
Body Color / Finish
Matte Black
