Description
Model: | G5.25XI |
Type: | Coaxial |
Size: | 5.25" |
RMS Power: | 45W |
MAX Power: | 135W |
Frequency response: | 90Hz - 20KHz |
Impedance: | 4 ohms |
Sensitivity: | 83dB/w/m |
Materials | |
Surround: | Rubber Edge |
Cone: | Black Paper |
Voice Coil Wire: | ASV |
Measurements | |
Voice coil size: | 1"(25mm) |
Magnet Size: | 70x32x12mm |
Tweeter Size: | 28mm Mylar Balanced Dome Top (No Grill); 56mm |
Mounting depth: | Top (w/Grill): 75mm Bottom: 49mm |
Cut-out dimension: | 139-4mm (5x9") |
