Description
Nominal Diameter: | 8" (203.2mm) |
Nominal Impedance: | 4 Ohms |
RMS Power Handing: | 275 Watts |
MAX Power Handing: | 550 Watts |
Sensitivity (1w/1m): | 98dB |
Frequency Response: | 65Hz - 22KHz |
Recommended Hi Pass Crossover: | 80Hz |
Midrange | |
Voice Coil Diameter: | 1.5" (38.1 mm) |
Voice Coil Former Material: | Kapton |
Winding Material: | CCAW |
Basket Material: | Steel |
Magnet Material: | 27 oz |
Tweeter | |
Voice Coil Diameter: | 1" |
Voice Coil Material: | Kapton |
Winding Material: | CCAW |
Diaphragm Material: | Aluminum Alloy |
Magnet Weight: | 0.44 oz |
Magnet Material: | Neodymium (N38H) |
Thiele & Small Parameters | |
Equivalent Volume / Vas | 12.4021 LTR |
Excursion / Xmax | 16mm |
Free Air Resonance / Fs | 110 Hz |
Mechanical Factor / Qms | 3.906 |
Electrical Factor / Qtes | 0.76 |
Total Factor / Qts | 0.636 |
DC Resistance / Re | 3.2 ohms |
Measurements | |
Overall Diameter: | 214 mm (8.42") |
Front Mount Baffle Cutout: | 181 mm (7.13") |
Mounting Depth: | 91 mm (3.58") |
Overall Depth: | 113 mm (4.44") |
