| Continuous Power Handling (RMS) | 600 W |
| Recommended Amplifier Power (RMS) | 200 - 600 W |
| Nominal Impedance (Znom) | Dual 4 Ω |
Physical Specifications
| Nominal Diameter | 10.0 in / 250 mm |
| Overall Diameter (A) | 10.5 in / 267 mm |
| Mounting Hole Diameter (B) | 9.02 in / 229 mm |
| Bolt Hole Circle Diameter (C) | 9.86 in / 250 mm |
| Motor Outer Diameter (D) | 6.3 in / 160 mm |
| Required Pole Vent Clearance | 0.50 in / 13 mm |
| Mounting Depth (E) | 6.89 in / 175 mm |
| Driver Displacement | 0.078 cu ft / 2.1 L |
| Net Weight | 20 lb / 9.1 kg |
Parameters
| Free Air Resonance (Fs) | 30.12 Hz |
| Electrical “Q” (Qes) | 0.543 |
| Mechanical “Q” (Qms) | 9.228 |
| Total Speaker “Q” (Qts) | 0.513 |
| Equivalent Compliance (Vas) | 0.821 cu ft / 23.25 L |
| One-Way Linear Excursion (Xmax)* | 0.75 in / 19 mm |
| Reference Efficiency (no) | 0.11% |
| Efficiency (1 W / 1 m)** | 82.7 dB SPL |
| Effective Piston Area (Sd) | 49.303 sq in / 0.0318 sq m |
| DC Resistance (Re)*** | 6.452 Ω |
