| Continuous Power Handling (RMS) | 35 W |
| Peak Music Power | 105 W |
| Recommended Amplifier Power (RMS) | 10 - 50 W / Ch. |
| System Efficiency | 84.5 dB @ 1 W / 1 m |
| System Nominal Impedance | 4 Ω |
| System Frequency Response | 71 Hz - 22 KHz ± 3 dB |
Coaxial Physical Specifications
| Frame Outer Diameter* (A) | 4.02 in / 102 mm |
| Grille Tray Outer Diameter (B) | 5.20 in / 132 mm |
| Motor Outer Diameter (C) | 2.36 in / 60 mm |
| Frontal Coaxial Tweeter Protrusion** (D) | 0.56 in / 14 mm |
| Frontal Grille Protrusion*** (E) | 0.66 in / 17 mm |
| Mounting Hole Diameter (F) | 3.81 in / 97 mm |
| Mounting Depth (G) | 1.81 in / 46 mm |
