| Continuous Power Handling (RMS) | 60 W |
| Peak Music Power | 225 W |
| Recommended Amplifier Power (RMS) | 15 - 100 W / Ch. |
| System Efficiency | 89.0 dB @ 1 W / 1 m |
| System Nominal Impedance | 4 Ω |
| System Frequency Response | 63 Hz - 22 KHz ± 3 dB |
Coaxial Physical Specifications
| Frame Outer Diameter* (A) | 5.20 in / 132 mm |
| Grille Tray Outer Diameter (B) | 6.01 in / 153 mm |
| Motor Outer Diameter (C) | 2.76 in / 70 mm |
| Frontal Coaxial Tweeter Protrusion** (D) | 0.46 in / 12 mm |
| Frontal Grille Protrusion*** (E) | 0.72 in / 18 mm |
| Mounting Hole Diameter (F) | 4.56 in / 116 mm |
| Mounting Depth (G) | 2.50 in / 64 mm |
