General Specifications
| Continuous Power Handling (RMS) | 70 W |
| Peak Music Power | 225 W |
| Recommended Amplifier Power (RMS) | 15 - 125 W / Ch. |
| System Efficiency | 93 dB @ 1 W / 1 m |
| System Nominal Impedance | 4 Ω |
| System Frequency Response | 53 Hz - 22 KHz ± 3 dB |
Coaxial Physical Specifications
| Frame Outer Diameter* (A) | 6.40 x 9.33 in / 163 x 237 mm |
| Grille Tray Outer Diameter (B) | 6.75 x 9.63 in / 172 x 245 mm |
| Motor Outer Diameter (C) | 3.94 in / 100 mm |
| Frontal Coaxial Tweeter Protrusion** (D) | 0.75 in / 19 mm |
| Frontal Grille Protrusion*** (E) | 0.98 in / 25 mm |
| Mounting Hole Diameter (F) | N/A |
| Mounting Depth (G) | 3.06 in / 78 mm |
