Nemesis Audio NA-BZ200X4D 4-Channel Class D Amplifier

The Nemesis Audio NA-BZ200X4D delivers powerful full-range performance in a compact footprint. Designed using efficient Class D technology, this amplifier produces clean, dynamic output while generating less heat and drawing less current than traditional amplifier designs.

Perfect for powering front and rear speakers or component audio systems, the NA-BZ200X4D offers stable 2 Ohm operation and flexible crossover controls for a wide variety of vehicle audio installations.

Features

• 800 Watts RMS maximum output
• Compact full-range Class D design
• 2 Ohm stable
• Selectable High Pass and Low Pass filters
• Variable input sensitivity
• High efficiency operation
• Compact chassis for easy installation

RMS Power

• 4 × 140W @ 4 Ohm
• 4 × 230W @ 2 Ohm
• 2 × 460W @ 4 Ohm Bridged

Specifications

• Working Impedance: 2 Ohm Stable
• Input Sensitivity: 0.2V to 12V
• High Pass Filter: 90Hz
• Low Pass Filter: 90Hz
• Subsonic Filter: N/A
• Bass Boost: 12dB
• Frequency Response: 20Hz to 20kHz
• Signal to Noise Ratio: 85dB
• THD @ 4 Ohm: 0.4%
• Operating Voltage: 9V to 16V
