The Nemesis Audio NA-BZ5000D is a high-power mono full range Class D amplifier made for demanding car audio systems. Delivering up to 5000W RMS at 1 ohm, it is built for customers who need serious output and stable performance.
Specifications
-
Amplifier Type: Mono full range Class D
-
RMS Power @ 4 Ohms: 1 x 1600W
-
RMS Power @ 2 Ohms: 1 x 3200W
-
RMS Power @ 1 Ohm: 1 x 5000W
-
Working Impedance: 1 Ohm stable
-
Input Sensitivity: 0.25V to 4V
-
Low Pass Filter: 50Hz to 20kHz
-
Subsonic Filter: 10Hz to 80Hz
-
Bass Boost: 0dB to 12dB
-
Frequency Response: 10Hz to 20kHz
-
Signal-to-Noise Ratio: 85dB
-
THD @ 4 Ohms: 0.4%
-
Operating Voltage: 9V to 16V
-
Fuse Rating: 350A
-
Dimensions: 10.20 x 8.35 x 2.56 in
Use the NA-BZ5000D for larger builds that require more headroom, stronger output, and dependable BZ Series power.
