Description
Subwoofer Pride M16.15
We present you one of the most popular models of our subwoofers range. It is Pride M.16 15” is a model with impeccable characteristics that allows you to achieve clear music sound. They have decent build quality.
A new era in the history of car audio is now in your hands. Aluminum frames that act as radiators and an updated cooling system provide maximum protection against overheating, which means the ability to sound long and loud. The subwoofers received a new magnetic system and a highly linear suspension – additional points in reliability and power. Enlarged centering washer with progressive corrugation shape. The shape of the diffuser made it possible to reduce the additional mass of the moving part and increase the area of adhesive contacts, which provides even more strength under high loads.
RMS – 1600W
Voice coil – 3,2″ round copper
Size – 15”
The distinctive properties of our subwoofers are the high quality of the raw materials, their wear resistance and long service life, which means that your speaker system from Pride Car Audio will work properly for many years.
Subwoofer available in the USA!
Part number: M16.15D16
General feature | |
---|---|
Power Handling (RMS) | 1600 W |
VC diameter / material | 3,2" round copper |
VC wire insulation | Polyimide |
Frame material | Aluminum |
Magnet size and q-ty | 190*25mm x 2 pcs / 7,48*0,98" x 2 pcs |
Spider diameter and q-ty | 230 mm x 4 pcs / 9,06" x 4 pcs |
Cone material | Paper with glass fiber |
Dust cap material | Hi-temp ABS |
Parameters | |
DC Resistance (Re) | 1,5+1,5 Ω |
Free Air Resonance (Fs) Hz | 26,6 |
Moving Mass (Mms) g | 476 |
BL Tm | 21,7 |
Total Speaker “Q” (Qts) | 0,45 |
Electrical Q (Qes) | 0,48 |
Mechanical Q (Qms) | 4,88 |
Equivalent Compliance (Vas) L | 64,3 |
One-Way Linear Excursion (Xmax) (BL 50%) mm | 21 |
Sensitivity (1 W / 1 m) dB | 86,2 |
Effective Piston Area (Sd) cm² | 845 |
Physical Specifications | |
Overall Diameter | 397mm / 15,63" |
Mounting Hole Diameter | 370mm / 14,57" |
Mounting Depth | 200mm / 7,87" |
Driver Displacement | 5 l / 1,32 Gal |
Net Weight | 13,6 kg / 29,98 lbs |
