Subwoofer Pride M9.12
Are you looking for a subwoofer for your car with impeccable performance and clear music sound? Then don’t miss the new model of the Pride M9 12 car subwoofer!
This subwoofer replaces the Pride Sapphire 12 and features 900W RMS power, a 2.6-inch voice coil, and an impedance of 1.85+1.85 ohms. The collapsible basket ensures clear music sound.
In addition, this subwoofer has a high build quality and is ready to please you with powerful bass in your favorite songs. You will not regret purchasing the Pride M9 12 – this is the best solution for your car music system!
Subwoofers manufactured by the leading company Pride stand out among their analogues with the following advantages:
Hot pressing of the washers and the use of woven material for the centering washers allows you to realize the full potential of the speaker under various operating conditions.
Automated gluing of magnetic systems to test the magnetic system according to all characteristics.
Special glue for each unit of the Pride acoustics allows for maximum strength and elasticity of the moving units.
Acoustic meshes are designed individually for the entire model range, therefore they effectively protect diffusers from mechanical damage
Please yourself with powerful bass, clear sound and reliable equipment with Pride Car Audio!
Subwoofer available in the USA!
Part number: M9.12D18
General feature | |
---|---|
Power Handling (RMS) | 900 W |
VC diameter / material | 2,5" round copper |
VC wire insulation | Polyimide |
Frame material | Steel |
Magnet size and q-ty | 156*24mm x 2 pcs / 6,14*0,94" x 2 pcs |
Spider diameter and q-ty | 193mm x 3 pcs / 7,6" x 3 pcs |
Cone material | Paper with glass fiber |
Dust cap material | Hi-temp ABS |
Parameters | |
DC Resistance (Re) | 0,4 Ω |
Free Air Resonance (Fs) Hz | 32,8 |
Moving Mass (Mms) g | 252 |
BL Tm | 5,3 |
Total Speaker “Q” (Qts) | 0,61 |
Electrical Q (Qes) | 0,69 |
Mechanical Q (Qms) | 5,26 |
Equivalent Compliance (Vas) L | 31,8 |
One-Way Linear Excursion (Xmax) (BL 50%) mm | 17 |
Sensitivity (1 W / 1 m) dB | 85,3 |
Effective Piston Area (Sd) cm² | 465 |
Physical Specifications | |
Overall Diameter | 316mm / 12,44" |
Mounting Hole Diameter | 280mm / 11,02" |
Mounting Depth | 152,5mm / 6" |
Driver Displacement | 2,5 l / 0,66 Gal |
Net Weight | 7,9 kg / 17,42 lbs |
