- 5-channel marine subwoofer amplifier
- 100 watts RMS CTA-2006 x 4 + 400 watts RMS x 1 at 4 ohms
- 100 watts RMS CTA-2006 x 4 + 600 watts RMS x 1 at 2 ohms
- 400 watts RMS CTA-2006 x 2 at 4 ohms + 600 watts RMS x 1 at 2 ohms
- max Dynamic Power rating: 200 watts x 4 + 700 watts x 1 at 2 ohms
- amplifier design: Class AD (channels 1-4); Class BD (sub channel)
- frequency response: 10-50,000 Hz
- variable low-pass and high-pass filters (50-250 Hz, 12 dB/octave)
- switchable subsonic filter (30 Hz, 12 dB/octave)
- variable bass boost (0-18 dB at 45 Hz)
- marine features:
- Element Ready™ chassis and conformal-coated PC boards
- IPX6 water intrusion rating
- heavy-duty molded connectors protect wiring from water and dirt
- Preset button for instant tuning in Rockford Fosgate UTV audio packages
- C.L.E.A.N. gain setup system includes clip lights
- auto remote turn-on
- preamp and speaker-level inputs
- preamp outputs
- wiring, fuse, and hardware not included with amplifier
- 4-gauge power and ground leads and a 200-amp fuse recommended
- dimensions: 17"W x 1-13/16"H x 4-1/4"D
- 5-Channel powersports amplifier
- 11" Power/ground/turn-on & subwoofer output harness (installed on amp)
- 11" Input harness (installed on amp)
- Three 14" RCA-to-Molex input adapters
- Power/ground/turn-on adapter plug
- Subwoofer output adapter plug
- Two 7.5" speaker output harnesses
- 3mm Allen key
- Owner's manual
Serious sound, made simple. The M5 amplifiers feature the next level of Element Ready™ design from Rockford Fosgate that’s built as rugged as the outdoor environment it’s used in.
Element Ready™: Purpose Built for the Marine Environment, Rockford’s Element Ready™ products are built to stand up to Water, Salt, and UV, making sure your amplifiers stand the test of time.
C.L.E.A.N.: Our Patented circuit with input and output clip indicators help match the source unit to the amplifier, which makes for easy set-up and optimizes musical output.
P.O.W.E.R. Supply: The unique P.O.W.E.R. supply continues to generate more than rated power as the voltage increases, giving you the output, you demand.
