Description
FEATURES
- High Fidelity Class A/B Multi-Channel Design
- 12dB/Octave-Variable Subsonic Filter
- 12dB/Octave-Variable High Pass Filter
- 12dB/Octave-Variable Low Pass Filter
- Clipping Indicator
- 4 Way Protection Circuit (Thermal,
- Voltage Speaker short and DC Offset)
- Optional Wired Remote Control with Clipping Indicator
SPECIFICATIONS
- Input Sensitivity 6V Max
- 300 x 4 @ 2 ohms RMS
- 200 x 4 @ 4 ohms RMS
- Variable High Pass Filter : 40HZ - 5kHZ
- -12dB/8 Variable Crossover Slope (LPF/HPF)
- Signal / Noise Ratio : 92DB
- Operation Voltage : DC 10.5V - 15.5V Power Input
- Dimensions : 19.29” L x 6.3” W x 2.75” H
