Description
FEATURES
- High Efficiency Digital Multi-Channel Design
- 12 dB/Octave – Variable Low Pass Filter
- 12 dB/Octave – Variable High Pass Filter
- Variable Bass Boost
- Clipping Indicator
- 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset)
- Optional Wired Remote Control with Clipping Indicator
SPECIFICATIONS
- 1 ohm RMS 500W / CH
- 2 ohm RMS 300W / CH
- 4 ohm RMS 200W / CH
- Recommended Fuse Rating 180A
- Low Pass Filter (Variable) 50Hz-6kHz
- High Pass Filter (Variable) 15Hz-6kHz
- Bass Boost @ 50Hz 0-12dB
- Input Sensitivity 5V Max
- S/N Ratio 100dB
- Working Voltage 10.5v-15.5v
- Dimensions 8.25″ x 9.75″ x 2.75″
