Description
- Sold Individually
- Power Handling: 120 Watts RMS
- Impedance: 4/8 Ohm
- Frequency Range: 20Hz - 10kHz
- Phase Plug
- Outside Diameter: 10.23"
- Cutout Diameter: 9.17"
- Mounting Depth: 3.25"
- Resonant Frequency, FS: 69.45Hz
- D.C.Voice coil resistance, Re: 3.3
- Mechanical quality factor, Qms: 13.22
- Electrical quality factor, Qes: 0.44
- Total quality factor, Qts: 0.42
- Equivalent air volume to Cms. Vas: 49.14L
- Mechanical compliance, Cms: 0.24MM/N
- BL factor, Bl: 6.3N/A
- Effective surface area,Sd: 12.469Mm*
- Sensitivitv(1w/1m): 96.18dB +/- 2dB
