The Smart 5 BASS is another innovation by Taramps. Aiming at car audio systems. The exclusive Power Control System technology, now specific for subwoofers, ensures even more quality at low frequencies delivering more security by monitoring the whole amplifier operation, It is multi-impedance, single-channel amplifier, that is, it delivers the 5000 WRMS in any impedance between 0.5 and 2 ohms. It has an indicative logo that you already know, robust power input, connecting cables up to 2 x 2/0 AWG (70mm²) and output for CLIP monitor. Feel the bass in an unforgettable way!
TECHNICAL INFORMATION
OPERATION CLASS | Class D |
---|---|
NUMBER OF CHANNELS | 01 |
MAXIMUM POWER | @ 14.4 VDC - 0,5 ohm: 5000 Watts RMS @ 14.4 VDC - 1 ohm: 5000 Watts RMS @ 14.4 VDC - 2 ohms: 5000 Watts RMS @ 14,.4 VDC - 4 ohms: 2700 Watts RMS |
INPUT SENSITIVITY | 4V ~ 0.2V |
SIGNAL TO NOISE RATIO | >90dB |
FREQUENCY RESPONSE | 8Hz ~ 200Hz (-3dB) |
CROSSOVER HIGH PASS (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
CROSSOVER LOW PASS (LPF) | 60Hz ~ 200Hz (-12dB/8ª) Variable |
BASS BOOST | Freq.: 35Hz ~ 55Hz Boost: 0 ~ +10dB |
EFFICIENCY | 76% @ 0.5 ohm 80% @ 1 ohm 84% @ 2 ohms |
INPUT IMPEDANCE | 10K ohms |
OUTPUT IMPEDANCE | 0.5 ~ 2 ohms |
PROTECTION SYSTEM | Short on output Short on output in relation to GND Low impedance protection High/low voltage protection Thermal protection. |
MIN. SUPPLY VOLTAGE | 9.5VDC |
MAXIMUM POWER SUPPLY VOLTAGE | 17VDC |
CONSUMPTION AT REST | 2.60A |
MAXIMUM MUSIC CONSUMPTION | 230A @ 0.5 ohm 215.5 @ 1 ohm 210 @ 2 ohms |
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 461A @ 0.5 Ohm 431 @ 1 ohm 420 @ 2 ohms |
DIMENSIONS (WXHXD) | 9.37" x 2.79" x 16.8" (238 x 71 x 427mm) |
WEIGHT | 12.79 lbs (5,80Kg) |
EAN | 7898556847483 |
